How to Turn Any Device Into a Bluetooth Receiver Using Raspberry Pi

One Methods:

The Raspberry Pi is one of the most versatile microcomputers on the planet. With a very active community and developers constantly upgrading the computers and making them cheaper. While many devices now come with Bluetooth capability that lets you link up your device to play music wirelessly, many older devices don't. Most devices come with an AUX port however. With a Raspberry Pi, the code provided in the article, and some time, you can have any device in your house ready to be Bluetooth stream-able. The code needed for each step at the bottom of the step is provided at the bottom of the article.

Steps

Designing The Speaker

  1. Download the latest version of Raspbian from the Raspberry Pi website and have it saved to your desktop.To get the file registered as an operating system, and not a zip file, you need to download win32 disk imager. Select the Raspbian file on your desktop as the image file, and select the removable disk as your device. Make sure the letter for the micro SD card is correct before you copy the file over so you don't overwrite the wrong drive. Once the image is finished copying over to the micro SD card, plug it into the Raspberry Pi and start it up.
  2. Use the default username, pi, and the default password, raspberry once Raspberry Pi has booted.Set up WiFi by either plugging in an Ethernet cable, or connect via WiFi by clicking on the icon at the top of the screen. Once you are finished setting up, you won't need WiFi anymore. The only reason you will need WiFi is to download the files.
  3. Download the software needed for this to work.In the command terminal, enter the code in line A and B. The code in line A downloads the latest version of the software. The code in line B allows Bluetooth to work with Pulseaudio, which is an open source program that acts as a server, allowing external inputs to broadcast sound to the device. Once the program is done downloading, we can start editing some config files to enable the Bluetooth.
    • A. sudo apt-get upgrade
    • B. sudo apt-get install bluez pulseaudio-module-bluetooth python-gobject python-gobject-2 bluez-tools
  4. Get ready to play music through the device by adding the user pi to pulse audio.In the terminal, enter the code from line A. This allows you to edit the default bluetooth streaming settings. Next, enable A2DP in the bluetooth configuration. A2DP is is a type of bluetooth streaming that lets us connect to other A2DP devices. It is a higher quality bluetooth connection than others since it can send more data faster. Enter the code from line B to open the config file.In the config file, under the [General]: tab, enter the code from line C. Use CTRL+O and ENTER to save, and CTRL+X to close the config file.
    • A. sudo usermod –a –G lp pi
    • B. sudo nano /etc/bluetooth/audio.conf
    • C. Enable=Source,Sink,Media,Socket
  5. Modify the Pulse Daemon config file, which is the configuration file for Pulseaudio.Enter the code from line A. You change the resampling method because you need to be able to convert the audio from different qualities so it can be used on your device. In the config file, look for the lineresample-method = speex-float-3, and add;at the beginning of the line so it looks like the code in line B. Then add line C below line B.
    • A. sudo nano /etc/pulse/daemon.conf
    • B. ;resample-method = speex-float-3
    • C. resample-method = trivial
  6. To have our devices automatically connect, you will need to edit some more config files.We need to edit the udev config files. In the terminal, enter the code from line A.Look for the lineSUBSYSTEM=="input", GROUP="input", MODE="0660"And under it, add the code from line B.Save your changes and exit the config file. Now you need to check and see if the udev/ directory exists by using the code from line C.If it does, move onto the next step, if not, enter the code from line D to create the directory.To fully get the bluetooth to work, you will have to copy the code from line E into a text editor and turn it into an executable file.Save and exit and then enter the code from line F.
    • A. sudo nano /etc/udev/rules.d/99-input.rules
    • B. KERNEL=="input[0-9]*", RUN+="/usr/lib/udev/bluetooth"
    • C. sudo ls –la /usr/lib/udev
    • D. sudo mkdir /usr/lib/udev
    • E. AUDIOSINK="alsa_output.platform-bcm2835_AUD0.0.analog-stereo"echo "Executing bluetooth script...|$ACTION|" >> /var/log/bluetooth_devACTION=$(expr "$ACTION" : "\([a-zA-Z]\+\).*")if [ "$ACTION"="add" ]thenhciconfig hci0 noscanamixer cset numid=3 1amixer set Master 100%pacmd set-sink-volume 0 65537   for dev in $(find /sys/devices/virtual/input/ -name input*)   do   if [ -f "$dev/name" ]   then      mac=$(cat "$dev/name" | sed 's/:/_/g')      bluez_dev=bluez_source.$mac      sleep 1      CONFIRM=`sudo -u pi pactl list short | grep $bluez_dev`      if [ ! -z "$CONFIRM" ]      then         echo "Setting bluez_source to:  $bluez_dev" >> /var/log/bluetooth_dev         echo pactl load-module module-loopback source=$bluez_dev sink=$AUDIOSINK rate=44100 adjust_time=0 >> /var/log/bluetooth_dev         sudo -u pi pactl load-module module-loopback source=$bluez_dev sink=$AUDIOSINK rate=44100 adjust_time=0 >> /var/log/bluetooth_dev      fi   fi   donefiif [ "$ACTION"="remove" ]thensudo hciconfig hci0 piscanFi
    • F. sudo chmod 774 /usr/lib/udev/bluetooth
  7. Create another script that turns on and off bluetooth discoverability when it starts up so we can connect our device to the Raspberry Pi.First, in the terminal, enter the code from line A. Now open up the text editor to create a new script. In the text editor, enter the code from line B into the document. Save the script and exit the text editor. Give the text file execute permissions so it can be launched when it is used. Make this script start up when the Raspberry Pi boots up. To do this, we need to enter the lines of code from C and D.
    • A. sudo nano /etc/init.d/bluetooth-agent
    • B. USER=rootHOME=/rootexport USER HOMEcase "" instart)echo "setting bluetooth discoverable"sudo hciconfig hci0 piscanstart-stop-daemon -S -x /usr/bin/bluetooth-agent -c pi -b -- 0000echo "bluetooth-agent started pw: 0000";;stop)echo "Stopping bluetooth-agent"start-stop-daemon -K -x /usr/bin/bluetooth-agent;;*)echo "Usage: /etc/init.d/bluetooth-agent {start|stop}"exit 1;;esacexit 0
    • C. sudo chmod 755 /etc/init.d/bluetooth-agent
    • D. sudo update-rc.d bluetooth-agent defaults
  8. Go to the inittab config file.Inittab is the file that tells the Raspberry Pi what to launch in certain situations, such as start up. To get to that config file, enter the code from line A And look for the following line of code1:2345:respawn:/sbin/getty 115200 tty1,add#before it so it gets commented out and won't be read by the program. It should look like the code in line B. Below it, add the code from line C.Save and exit. Now just reboot Raspberry Pi and you are ready to go.
    • A. sudo nano /etc/inittab
    • B. #1:2345:respawn:/sbin/getty 115200 tty1
    • C. 1:2345:respawn:/bin/login -f pi tty1 /dev/tty1 2>&1

Community Q&A

Search
Ask a Question
200 characters left
Include your email address to get a message when this question is answered.
  • One of the things you can do with this project is to set it up on a device and leave it. Since it has all the files needed to operate normally, with no internet connection, you can plug it into any device you want through the Aux port. You can use it to add bluetooth to your home stereo system, an old radio that you want to connect your phone to, or even your car, if you have a portable battery that can power it. No matter what you do though, you will want a simple case that just covers the Raspberry Pi so you don't have a bare circuit board that could get easily damaged. However, if you want to get more fancy, you can build a custom enclosure for your Raspberry Pi and have bluetooth speakers wherever you go.
  • The easiest option for a custom enclosure would be 3d printing one. Since you can design a case to your exact specifications, there would not be any wasted material. You can design it in any shape you want and have it easily fit all of your selected parts. The downsides of using a 3d printed case however, would be a weaker case, a possibly unattractive case, and 3d printers are expensive. Since 3d printers print with hardened plastic, it won't be as strong as other materials that you can make cases out of. Since 3d printers also only print in one color at a time, you would end up with a case in a  solid color that is made from solid plastic, which isn't one of the best looking materials. 3d printers are also very expensive, especially since this is supposed to be a budget device. A typical 3d printer costs at least 0 for a half decent, and reliable one. While this would be an easier option, it is potentially much more expensive than making a case yourself.
  • Another possibility for a case is building one yourself. A homebuilt case would not require any fancy, specialized tools and it can be built to any specification you choose. A homebuilt case can either be super cheap or super expensive depending on what you make it out of, and how you make it. Unlike the 3d printed case, there is no set cost of materials or tools. However, this also means you can go over budget if you are not careful. Since it is a custom built case, it can be made out of any material and be designed in any way you choose. You can make it as cheap as spare cardboard from a box,or as expensive as metal casing. For the home built case, more time will be needed since you have to build the case instead of having a 3d printer build it for you.
  • While all the case ideas have there advantages, there are also disadvantages with each one. While one option may work for one person, another option may not. Plug and play, like the first option, is the most simple since it involves hooking it up to your speakers at home and leaving it plugged in at all times. The 3d printed case could be the best option for someone who already has a 3d printer, and either wants a homemade bluetooth speaker, or wants a project to 3d print with. The home building one is the one with the most potential since it is the one that requires the most attention, but can also provide the best looks.
